Biocatalyst for Change, Part II: Strategies to Engineer Pigment Production

MetallicWomanMakeup850x425

Continued from Part I

Anthocyanins can be accumulated in different plant tissues when plants are subjected to biotic or abiotic stress, and several elicitors such as jasmonate.19,  20 Anthocyanins are synthesized via the general flavonoid pathway in plants, whereby three molecules of malonyl-CoA and one molecule of 4-coumaroyl-CoA derived from the general phenylpropanoid pathway are condensed to form naringenin chalcone by chalcone synthase (CHS), which then undergoes isomerization, hydroxylation and oxidation to form anthocyanidins (see Figure 1). Anthocyanidins are then glycosylated at C3 or other positions by flavonoid glucosyltransferases (FGTs) with the incorporation of glucose or other sugar units such as rhamnose, galactose, xylose, etc., giving rise to anthocyanins. Beyond glycosylation, other modifications, such as acylation and methylation of the hydroxyl groups have also been reported.21

As noted, the prevailing way to industrially produce anthocyanin is by extraction from plants, which is typically performed using solvents; most commonly ethanol, due to its environmentally friendly nature, safety profile and minimal interference with anthocyanin recovery.22 Other extraction methods such as pressurized liquid extraction and novel extraction tools/agents, e.g., ultrasound, subcritical water and polymeric absorber resins, also have been reported as effective for obtaining anthocyanins from crops and fruits.23-26

Plant suspension cell culture is another possible way to produce anthocyanins, which introduces the bioreactor concept to cultivate plant cells for anthocyanin production. This allows for tight control over the fermentation process and involves the development of suitable cell lines, optimization of operating conditions, and scale-up of fermentation.27, 28

For some time, plants such as grapes, Cleome rose, sweet potatoes, aspen, wild carrots, etc., have been used to develop anthocyanin-producing cell lines.29, 30 Currently, however, no systems that are commercially feasible are apparently available. This is due to the instability of cell lines, causing anthocyanin production to decrease drastically over time and other problems such as high production cost, low consumer acceptance and strict biosafety regulations on plant suspension cell cultures.31-33 Future efforts on the development of robust cell lines and efficient fermentation processes, in terms of light irradiation, temperature and medium composition, will drive the application of suspension cell culture in the production of anthocyanins or related products.

Anthocyanins from Microorganisms

Engineering microorganisms, especially model microorganisms such as E. coli and Saccharomyces cerevisiae, for the production of natural chemicals is a promising and sustainable way to satisfy production demands, owing to several distinct advantages of microorganisms: fast growth and easy cultivation, sophisticated engineering strategies and readily available metabolic network databases.

As the most commonly used workhorse in metabolic engineering, E. coli has been engineered for the production of anthocyanins as well as other flavonoid molecules (see Figure 2).21, 34-36 As early as 2005, the genes of F3H and ANS from Malus domestica; DFR from Anthurium andraeanum; and flavonoid 3-glucosyltransferase (F3GT) from Petunia hybrida were successfully expressed in E. coli, producing 6.0 μg/L of cyanidin 3-O-glucoside and 5.6 μg/L of pelargonidin 3-O-glucoside when fed with naringenin and eriodictyol as precursors.37 The subsequent optimization of enzyme sources and UDP-glucose pool, regulation of precursor uptake and optimization of the production process greatly increased final product titers.38-40

For metabolic engineering, E. coli has been the most commonly used workhorse to produce anthocyanins and flavonoids.

The highest production of cyanidin 3-O-glucoside and pelargonidin 3-O-glucoside achieved was 350 mg/L and 113 mg/L, based on catechin and afzelechin as the respective precursors. To date, the reported microbial hosts of anthocyanin biosynthesis are still limited to E. coli, although the heterologous production of other flavonoids has been extended to S. cerevisiae, Streptomyces venezuelae,21, 37 and Corynebacterium glutamicum.41-43 It remains to be seen if other microorganisms are better host strains in terms of anthocyanin production.

In the next sections, common strategies used for the development of anthocyanin-producing E. coli strains, as well as strategies for optimizing the fermentation process, are described.

Engineering Pathway Enzymes

The microbial production of anthocyanins involves the co-expression of enzymes from plants in the anthocyanin biosynthesis pathway, which is challenging; typically, plant-derived genes must be engineered prior to their functional expression. For example, to achieve the functional expression of a plant P450 F3'5'H from Catharanthus roseus in the biosynthesis of the flavonoid quercetin, a new F3'5'H was fused to a shortened P450-reductase from C. roseus to form a chimeric protein. To engineer F3'5'H, the first four amino acids at N-terminus were removed and the sixth amino acid was changed to alanine from leucine, followed by the replacement of the fifth codon with ATG as the new start codon.44

Translational fusion of multiple enzymes in successive steps is also a popular strategy for improving anthocyanin production. Such fusions can increase the local concentrations of substrates for each enzyme in enzyme complex while minimizing the degradation of unstable intermediates, achieving a high overall metabolic flux and titer.45 For example, the translational fusion of F3GT from Arabidopsis to the N-terminus of ANS from P. hybrida was shown to produce 16.9% more cyanidin 3-O-glucoside than the tandem expression of ANS and F3GT.38

Beyond the aforementioned enzyme engineering, selection of natural enzymes from diverse species is another approach to improve anthocyanin production.46 The orthologous enzymes usually exhibit diverse kinetic and thermodynamic properties, resulting in different metabolic behaviors and varied levels of production. For example, in one study, ANS from P. hybrida produced 0.47- to 4.9-fold more cyanidin 3-O-glucoside than from Antirrhinum majus, Gerbera hybrid and M. domestica in E. coli.36 In another study, different combinations of three 4-coumaroyl CoA ligases, two chalcone synthases and two chalcone isomerases led to a diverse landscape of naringenin production and a threefold increase of naringenin production in E. coli.47

The microbial production of natural chemicals has distinct advantages: fast growth and cultivation, sophisticated engineering and readily available metabolic network databases.

Controlling Cofactors

Besides pathway enzymes, the biosynthesis of anthocyanins relies on cofactors. For example, the enzyme ANS uses ferrous ions and sodium ascorbate as cofactors, and 2-oxoglutarate as a cosubstrate to carry out the two-electron oxidation of its substrates.38, 48 The glycosylation of cyanidin at the C3 position requires an equimolar amount of UDP-glucose and feeding trials have demonstrated the UDP-glucose supply is a limiting factor in anthocyanin production.38

However, in an E. coli strain that produced cyanidin 3-O-glucoside, its production could be increased 20-fold through the regulation of the UDP-glucose pool. Here, genes responsible for the biosynthesis of 3-O-glucoside from orotic acid, pyrE, pyrR, cmk, ndk, pgm and galU, were overexpressed while blocking the competitive UDP-glucose consumption pathways.38, 39

Also, S-adenosyl-L-methionine (SAM) provides methyl groups in the production of methylated anthocyanins. Its supply can be boosted by supplementing methionine and/or up-regulating genes associated with SAM biosynthesis. However, the accumulation of SAM is inhibited owing to feedback repression by the methionine biosynthesis regulator MetJ in response to the intracellular concentration of SAM.49 As another example, to increase the supply of SAM for the production of peonidin 3-O-glucoside—a purple-colored methylated anthocyanin—CRISPRi-mediated silencing of MetJ was employed in E. coli. Results showed a twofold increase in the production titer.50

Managing Anthocyanin Efflux

Natural product biosynthesis can result in the production of molecules that are toxic to cells, limiting their production in high yields. Therefore, a feasible solution is to continuously pump out the toxic products to extracellular media during the biosynthesis process.

For example, in an E. coli strain that converted catechin to cyanidin 3-O-glucoside, the overexpression of the product-associated efflux pump YadH increased the titer by 15%, and the deletion of another efflux pump TolC, which most likely expelled catechin inside cells, resulted in a 55% higher production. Further, the combined modification resulted in a 63% increase in cyanidin 3-O-glucoside production.40

Anthocyanins in plants are transported to vacuoles after their synthesis, and this process is accomplished by both cytoplasmic transporters and transmembrane transporters. Here, the most commonly studied plant-based transporters are glutathione S-transferase and ATP-binding cassette (ABC) transporters. It would be interesting to assess the performance of plant-based transporters in microorganisms for anthocyanin delivery and anthocyanin production.

Optimizing Biocatalysis

The instability of anthocyanins at a neutral pH is a major issue in their production by E. coli. Unlike plants, which can stabilize the synthesized anthocyanins by storing them in vacuoles, E. coli does not have this protection mechanism.51, 52 Instead, the produced anthocyanins are inclined to degrade, given that the intracellular and extracellular pH is around 7 under normal growth conditions.

To address this problem, a two-step biocatalysis strategy was developed, in which cells are first cultured in a medium at pH 7 to support cell growth and enzyme expression, and then are transferred to fresh medium at pH 5.0 to initiate anthocyanin production and accumulation in the second step.38 Protective agents such as glutamate can be added to minimize acid-induced cell lysis. Using this approach, the production of cyanidin 3-O-glucoside was increased by ~15-fold from the traditional single-step production.38

While challenges remain, microbial-produced anthocyanins are expected to be applied to commercial cosmetics in the near future.

Besides pH, induction points in time and temperature have remarkable effects on recombinant anthocyanin production.40, 47 Induction time-points are correlated with the growth state and conditions of producing cells, which can cause differential enzyme expressions and significantly different production efficiencies. Likewise, temperature generally imposes a direct impact on cell viability and protein expression or folding, and hence influences anthocyanin bioconversion indirectly.

Coculturing to Produce Anthocyanins De novo

Low-cost production is key to the commercialization of recombinant anthocyanins. To this end, increasing the conversion yield of precursor molecules such as catechin to C3G is one focus, whereas achieving efficient C3G production directly from cheaper precursors, such as glycerol and glucose, is another focus.

As such, a polyculture strategy was recently proposed53 that allows the metabolic burden to be divided into individual host strains to optimize each strain for the efficient conversion of a precursor molecule to an anthocyanin intermediate—and finally, to the end product of interest.54, 55

For example, the whole synthetic pathway from simple carbon sources such as glucose or glycerol to pelargonidin 3-O-glucoside was split into four modules and placed into four different E. coli strains. The modulation of the four-strain consortia successfully achieved the de novo production of pelargonidin 3-O-glucoside from glucose at 9.5 mg/L for the first time.

Conclusions and Future Perspectives

The preference for natural compounds such as anthocyanins with potential skin-protection benefits has inspired their application as cosmetic ingredients. The microbial production of anthocyanins has attracted considerable attention due to distinct advantages over traditional production methods. The present review summarizes successful strategies to improve the production of anthocyanins in E. coli; including engineering pathway enzymes, improving the availability of cofactors, engineering anthocyanin efflux pumps and optimizing the fermentation process.

Several challenges remain to be addressed prior to the commercialization of anthocyanin-producing bacteria; such as the poor expression of anthocyanin biosynthetic genes, an imbalance of genes in the pathway, the delivery and stabilization of final products, and safety assessments for the potency of microbial anthocyanins. However, with solutions to these issues, it can be expected that microbial anthocyanins will be applied in commercial cosmetics in the near future.

References

  1. A Lopaciuk and M Curie-Sklodowska, Global beauty industry trends in the 21st century, in (conference) Global beauty and personal care: The year in review and winning strategies for the future, Milan (2013)
  2. A Ribeiro, M Estanqueiro, M Oliveira and J Sousa Lobo, Main benefits and applicability of plant extracts in skin care products, Cosmetics 2(2) 48 (2015)
  3. T Aburjai and FM Natsheh, Plants used in cosmetics, Phytother Res 17(9) 987–1000 (2003)
  4. J Zha and MAG Koffas, Production of anthocyanins in metabolically engineered microorganisms: Current status and perspectives, Synth Syst Biotechnol 2(4) 259–266 (2017)
  5. S Chouhan, K Sharma, J Zha, S Guleria and MAG Koffas, Recent advances in the recombinant biosynthesis of polyphenols Front Microbiol 16(8) 2259 (2017)
  6. CF Chan, CY Lien, YC Lai, CL Huang and WC Liao, Influence of purple sweet potato extracts on the UV absorption properties of a cosmetic cream, J Cosmet Sci 61(5) 333–341 (2010)
  7. K Tsoyi, HB Park et al, Protective effect of anthocyanins from black soybean seed coats on UVB-induced apoptotic cell death in vitro and in vivo, J Agric Food Chem 56(22) 10600–10605 (2008)
  8. A Tarozzi, A Marchesi et al, Protective effects of cyanidin-3-O-beta-glucopyranoside against UVA-induced oxidative stress in human keratinocytes, Photochem Photobiol 81(3) 623–629 (2005)
  9. K Tsoyi, HB Park et al, Anthocyanins from black soybean seed coats inhibit UVB-induced inflammatory cylooxygenase-2 gene expression and PGE2 production through regulation of the nuclear factor-kappaB and phosphatidylinositol 3-kinase/Akt pathway, J Agric Food Chem 56(19) 8969–8974 (2008)
  10. A Westfall, Evaluation of the efficacy of anthocyanins as biologically active ingredients in lipstick formulations, Master thesis, Food Science and Technology, The Ohio State University, Columbus, OH (2015)
  11. AK Ghimeray, US Jung, HY Lee, YH Kim, EK Ryu and MS Chang, In vitro antioxidant, collagenase inhibition, and in vivo anti-wrinkle effects of combined formulation containing Punica granatum, Ginkgo biloba, Ficus carica and Morus alba fruits extract, Clin, Cosmet Invest Dermatol 8 389–396 (2015)
  12. PK Mukherjee, N Maity, NK Nema and BK Sarkar, Bioactive compounds from natural resources against skin aging, Phytomedicine 19(1) 64–73 (2011)
  13. L Zhu, Y Huang, Y Zhang, C Xu, J Lu and Y Wang, The growing season impacts the accumulation and composition of flavonoids in grape skins in two-crop-a-year viticulture, J Food Sci Technol 54(9) 2861–2870 (2017)
  14. P-J Tsai, S-C Wu and Y-K Cheng, Role of polyphenols in antioxidant capacity of napiergrass from different growing seasons, Food Chem 106(1) 27–32 (2008)
  15. Q Zhang, NP Botting and C Kay, A gram scale synthesis of a multi-13C-labelled anthocyanin, [6,8,10,3',5'-13C5]cyanidin-3-glucoside, for use in oral tracer studies in humans, Chem Commun 47(38) 10596–10598 (2011)
  16. L Cruz, N Mateus and V de Freitas, First chemical synthesis report of an anthocyanin metabolite with in vivo occurrence: Cyanidin-4'-O-methyl-3-glucoside, Tetrahedron Lett 54(22) 2865–2869 (2013)
  17. M Saniewski, A Miszczak et al, Effects of methyl jasmonate on anthocyanin accumulation, ethylene production and CO2 evolution in uncooled and cooled tulip bulbs, J Plant Growth Regul 17(1) 33–37 (1998)
  18. R Akula and GA Ravishankar, Influence of abiotic stress signals on secondary metabolites in plants, Plant Signaling Behav 6(11) 1720–1731 (2011)
  19. RP Pandey, P Parajuli, MAG Koffas and JK Sohng, Microbial production of natural and non-natural flavonoids: Pathway engineering, directed evolution and systems/synthetic biology, Biotechnol Adv 34(5) 634–662 (2016)
  20. F Delgado-Vargas and O Paredes-Lopez, Natural Colorants for Food and Nutraceutical Uses, CRC Press, Boca Raton, FL USA (2002)
  21. M Corrales, S Toepfl, P Butz, D Knorr and B Tauscher, Extraction of anthocyanins from grape by-products assisted by ultrasonics, high hydrostatic pressure or pulsed electric fields: A comparison, Innovative Food Sci Emerging Technol 9(1) 85–91 (2008)
  22. Z Ju and LR Howard, Subcritical water and sulfured water extraction of anthocyanins and other phenolics from dried red grape skin, J Food Sci 70(4) S270–S276 (2005)
  23. 23. D Kammerer, J Gajdos Kljusuric, R Carle and A Schieber, Recovery of anthocyanins from grape pomace extracts (Vitis vinifera L. cv. Cabernet Mitos) using a polymeric adsorber resin, Eur Food Res Technol 220(3) 431–437 (2005)
  24. ZY Ju and LR Howard, Effects of solvent and temperature on pressurized liquid extraction of anthocyanins and total phenolics from dried red grape skin, J Agric Food Chem 51(18) 5207-5213 (2003)
  25. A Matkowski, Plant in vitro culture for the production of antioxidants—A review, Biotechnol Adv 26(6) 548–560 (2008)
  26. S Deroles, Anthocyanin biosynthesis in plant cell cultures: A potential souce of natural colorants, in Anthocyanins, Springer, New York (2008) pp 108–167
  27. C Simões, N Albarello, TC de Castro and E Mansur, Production of anthocyanins by plant cell and tissue culture strategies, in Biotechnological Production of Plant Secondary Metabolites, Bentham Science Publishers, Sharjah, UAE (2012) pp 67–86
  28. SR Rao and GA Ravishankar, Plant cell cultures: Chemical factories of secondary metabolites, Biotechnol Adv 20(2) 101–153 (2002)
  29. J Zha and MAG Koffas, Anthocyanin production in engineered microorganisms, in Biotechnology of Natural Products, Springer, New York (2018) pp 81–97
  30. A Angelov and V Gotcheva, Safety assessment and regulations for food ingredients derived from plant in vitro systems, in Bioprocessing of Plant In vitro Systems, Springer, New York (2017) pp 1–17
  31. A Ananga, V Georgiev, J Ochieng, B Phills and V Tsolova, Production of anthocyanins in grape cell cultures: A potential source of raw material for pharmaceutical, food, and cosmetic industries, in The Mediterranean Genetic CodeGrapevine and Olive, InTech (2013)
  32. JA Chemler, E Leonard and MAG Koffas, Flavonoid biotransformations in microorganisms, in Anthocyanins: Biosynthesis, Functions and Applications, Springer, New York (2009) pp 191–255
  33. EA Trantas, MA Koffas, P Xu and F Ververidis, When plants produce not enough or at all: Metabolic engineering of flavonoids in microbial hosts, Front Plant Sci 6 7 (2015)
  34. JA Chemler and MAG Koffas, Metabolic engineering for plant natural product biosynthesis in microbes, Curr Opin Biotechnol 19(6) 597–605 (2008)
  35. Y Yan, J Chemler, L Huang, S Martens and MAG Koffas, Metabolic engineering of anthocyanin biosynthesis in Escherichia coli, Appl Environ Microbiol 71(7) 3617–3623 (2005)
  36. Y Yan, Z Li and MA Koffas, High-yield anthocyanin biosynthesis in engineered Escherichia coli, Biotechnol Bioeng 100(1) 126–140 (2008)
  37. E Leonard, Y Yan, ZL Fowler, Z Li, C-G Lim, K-H Lim and MAG Koffas, Strain improvement of recombinant Escherichia coli for efficient production of plant flavonoids, Mol Pharmaceutics 5(2) 257–265 (2008)
  38. CG Lim, L Wong et al, Development of a recombinant Escherichia coli strain for overproduction of plant pigment, anthocyanin, Appl Environ Microbiol 81(18) 6276–6284 (2015)
  39. N Kallscheuer, M Vogt, A Stenzel, J Gatgens, M Bott and J Marienhagen, Construction of a Corynebacterium glutamicum platform strain for the production of stilbenes and (2S)-flavanones, Metab Eng 38 47–55 (2016)
  40. N Kallscheuer, M Vogt and J Marienhagen, A novel synthetic pathway enables microbial production of polyphenols independent from the endogenous aromatic amino acid metabolism, ACS Synth Biol 6(3) 410–415 (2017)
  41. PV van Summeren-Wesenhagen and J Marienhagen, Putting bugs to the blush: Metabolic engineering for phenylpropanoid-derived products in microorganisms, Bioengineered 4(6) 355–362 (2013)
  42. E Leonard, Y Yan and MAG Koffas, Functional expression of a P450 flavonoid hydroxylase for the biosynthesis of plant-specific hydroxylated flavonols in Escherichia coli, Metab Eng 8(2) 172–181 (2006)
  43. K Springob, J Nakajima, M Yamazaki and K Saito, Recent advances in the biosynthesis and accumulation of anthocyanins, Nat Prod Rep 20(3) 288–303 (2003)
  44. S Zhao, JA Jones, DM Lachance, N Bhan, O Khalidi, S Venkataraman, Z Wang and MAG Koffas, Improvement of catechin production in Escherichia coli through combinatorial metabolic engineering, Metab Eng 28 43–53 (2015)
  45. JA Jones, VR Vernacchio, AL Sinkoe, SM Collins, MHA Ibrahim, DM Lachance, J Hahn and MAG Koffas, Experimental and computational optimization of an Escherichia coli co-culture for the efficient production of flavonoids, Metab Eng 35 55–63 (2016)
  46. JJ Turnbull, J-i Nakajima, RWD Welford, M Yamazaki, K Saito and CJ Schofield, Mechanistic studies on three 2-oxoglutarate-dependent oxygenases of flavonoid biosynthesis: Anthocyanidin synthase, flavonol synthase and flavanone 3β-hydroxylase, J Biol Chem 279(2) 1206–1216 (2004)
  47. R Martí-Arbona, M Teshima et al, Identification of new ligands for the methionine biosynthesis transcriptional regulator (MetJ) by FAC-MS, J Mol Microbiol Biotechnol 22(4) 205–214 (2012)
  48. BF Cress, QD Leitz et al, CRISPRi-mediated metabolic engineering of E. coli for O-methylated anthocyanin production, Microb Cell Fact 16(1) 10 (2017)
  49. Y Zhang, E Butelli and C Martin, Engineering anthocyanin biosynthesis in plants, Curr Opin Plant Biol 19 81–90 (2014)
  50. V Passeri, R Koes and FM Quattrocchio, New challenges for the design of high value plant products: Stabilization of anthocyanins in plant vacuoles, Front Plant Sci 7 153 (2016)
  51. JA Jones, VR Vernacchio et al, Complete biosynthesis of anthocyanins using E. coli polycultures, mBio 8(3) (2017)
  52. H Zhang and X Wang, Modular co-culture engineering, a new approach for metabolic engineering, Metab Eng 37 114–121 (2016)
  53. Z Fang, JA Jones, J Zhou and MAG Koffas, Engineering Escherichia coli co-cultures for production of curcuminoids from glucose, Biotechnol J 13(5) e1700576 (2018)
  54. http://nutrasorb.com/downloads/Product-Information-Rutgers-Scarlet-Lettuce-Extract-CS.pdf (Accessed Jun 12, 2018)
  55. https://phys.org/news/2017-06-strains-bacteria-pigment-food-cosmetics.html (Accessed Jun 12, 2018)
